Introduction

On the AutoCAD command line, enter FIELDISPLAY system variable. When prompted for a new value, type 0.

Quick Answer, how do I remove background mask in AutoCAD?

Moreover, how do I hide the background in AutoCAD? To turn off the background mask, double-click the text to go back into the Multiline Text Editor and click the Background Mask button. In the Background Mask dialog, clear the Use background mask checkbox, and then click OK.

As many you asked, how do I change the background mask in AutoCAD?

You asked, how do I hide objects behind text in AutoCAD?

1. On the Ribbon, go to Home tab > Expand Annotation drop-down > Dimension styles manager.
2. Select the Dimension style to change and click Modify.
3. Go to Text tab > Text appearance.
4. From the Fill color drop-down, choose Background.
5. Confirm all windows with OK.

Use combination Ctrl+H (or Pickstyle set to zero) then delete the wipeout.

What is a wipeout in AutoCAD?

The Wipeout command is used to hide some parts of the drawing without deleting them. It is an object of the background color, the borders of which have a different color and can be hidden.

How do I make the background white in AutoCAD?

1. Click Application button > Options.
2. In the Options dialog box, Display tab, click Colors.
3. In the Drawing Window Colors dialog box, select the context and the interface element that you want to change.
4. On the Color list, select the color that you want to use.

How do I make text background transparent in AutoCAD?

In the Type Properties window which should now be on screen, select the Text type from the drop down list or create a new one. Then under Graphics ►Background, click Opaque and switch it to Transparent.

How do you mask a viewport in AutoCAD?

Go to Solution. In MODEL SPACE place a wipeout behind all of the objects in the drawing. Now in paper space your viewports will all have a mask. Use “draworder” on the viewports to control which one is masked.

How do I make a background mask?

How do I mask an image in AutoCAD?

To display and plot a subset of the images in your drawing, you can create a mask. You can bypass the New Image Mask dialog box by typing -imask on the command line. You can edit the vertices of a mask by selecting and moving them using AutoCAD grips.

How do I turn off isolate layers in AutoCAD?

1. Begin the LAYISO command.
2. Before you click anything look at the command line.
3. Select the “Settings” option.
4. By default the “Lock and fade” options is set. Select the “Off” setting.
5. Verify the “Off” setting is also set for the paper space viewport option.
6. Continue to use the command as you normally would.

How do I remove the hatch behind text in AutoCAD?

How do you exit isolate in AutoCAD?

1. Select any object in the current view.
2. Click
