After several searches on the internet on a question like Quick answer: How to add cutting plane line in autocad?, I could see the lack of information on CAD software and especially of answers on how to use for example AutoCAD. Our site CAD-Elearning.com was created to satisfy your curiosity and give good answers thanks to its various AutoCAD tutorials and offered free.
Engineers in the fields of technical drawing use AutoCAD software to create a coherent design. All engineers must be able to meet changing design requirements with the suite of tools.
This CAD software is constantly modifying its solutions to include new features and enhancements for better performance, more efficient processes.
And here is the answer to your Quick answer: How to add cutting plane line in autocad? question, read on.
Introduction
- Choose Home tab→Drawing Views group→Cutting Plane .
- Click a part view.
- Draw the cutting plane.
- When you are finished drawing the cutting plane, on the ribbon, click Close Cutting Plane .
- Click to define the section view direction.
Also know, how do I create a cutting line in AutoCAD?
In this regard, how do I add a section cut to a line in AutoCAD?
- Click Home tab Detail panel Section Line.
- Select a starting point for the section line .
- Select the next point or points for the section line and press ENTER.
- Enter a letter to reference the section line at the starting point.
- Press ENTER.
Moreover, how do you cut a plane line in AutoCAD 2020?
Quick Answer, how do you show the cutting line? To hide the cutting line in the parent view, right-click on either the cutting line or the section view and click Hide Section Line. To show a hidden cutting line, right-click on the section view and click Show Section Line.
- Choose Home tab→Drawing Views group→Cutting Plane .
- Click a part view.
- Draw the cutting plane.
- When you are finished drawing the cutting plane, on the ribbon, click Close Cutting Plane .
- Click to define the section view direction.
What is a cutting plane line?
Cutting Plane: An imaginary plane along which a section is taken. Cutting Plane Line: A line on a normal view that shows where the cutting plane passes through the object. It is used to show where the object is being cut.
How do you cut a section in CAD?
- Click Layout tab Create View panel Section drop-down Full.
- Click the view you want to use as the parent view.
- Click in the drawing area to indicate the start point of the section line.
What is section plane command in AutoCAD?
The section plane AutoCAD object is represented by a special line object that defines the section plane through the 3D model and provides a way to analyze that model by moving the section object to various points through the object.
What is short break line?
Short break lines are thick, wavy solid lines that are drawn freehand. When either of these break lines is used to shorten an object, you can assume that the section removed from the part is identical to the portions shown on either side of the break. (thin and long with a zigzag)
What is the difference between cutting plane lines and viewing plane lines?
Viewing or Cutting Plane Lines. VIEWING PLANE LINES are used to indicate the plane or planes from which a surface or several surfaces are viewed. CUTTING PLANE LINES are used to indicate a plane or planes in which a sectional view is taken.
Which type of line is used to show the edge view of cutting plane?
Cutting planes. Cutting plane lines which show where the cutting plane passes through the object, represent the edge view of the cutting plane and are drawn in the view(s) adjacent to the section view.
How do I cut a section of a plan?
Is a type of section where the cutting plane is drawn horizontally?
Sectional Top View: When an object is cut by a horizontal cutting plane or Auxiliary Inclined Plane, the top view obtained is called the Sectional Top View.
Where is the cutting plane line drawn?
Cutting plane lines are thick lines that run through the center of the object that the interior wants to provide an interior view of. Two perpendicular lines with arrows showing in which direction the interior of the object should be viewed are drawn at the end of the line.
How cutting planes are represented?
A cutting plane is represented on a drawing by a cutting plane line. This is a heavy long-short-short-long kind of line terminated with arrows. The arrows in show the direction of view. Once again, here is an graphic example of a cutting plane line and the section that develops from it.
How are cutting planes section planes drawn?
The Cutting Plane command draws a cutting plane line on the part view you want to use as the basis for the section view. Cutting planes can be used just once. You can draw the cutting plane on any part view. This can be any orthographic, auxiliary, or detail view on the drawing.
What is the two types of cutting plane line?
There are two forms of cutting plane lines approved for engineering drawings. The first form consists of evenly spaced dashes with arrowheads indicating the direction of sight. The second form consists of alternating long dashes and pairs of short dashes.
How do you show section planes in AutoCAD?
How do you use section plane?
How do you create a plane in Autocad?
Create a plane Additional planes can be created by using Draw Draw New Sketch Plane, or by right-clicking on the Planes branch of the tree view and choosing New Plane. You can select between the three planes parallel to the global axes (XY, YZ or XZ).
Bottom line:
I hope this article has explained everything you need to know about Quick answer: How to add cutting plane line in autocad?. If you have any other questions about AutoCAD software, please take the time to search our CAD-Elearning.com site, you will find several AutoCAD tutorials. Otherwise, don’t hesitate to tell me in the comments below or through the contact page.
