Introduction
You might be looking for Properties — select the element(s) in question, then Ctrl+I (or right click hold, Properties…) Under User Interface the last section Dialog Name Changes and Moves lists some familiar dialog boxes and what’s become of them, including the Element Information dialog.
Additionally, how do I see element attributes in MicroStation? You can also review or modify MicroStation drawing information about an element(s), such as its type, attributes, and geometry, by using the Element Information dialog. To access the Element Information dialog, click the Element Information button or click the Element menu and select the Information command.
Considering this, how do I find coordinates in MicroStation? The Geographic Coordinate System dialog is used to report, select or delete a GCS for the current model in a design file. Find this dialog from the MicroStation Tools menu, select Geographic > Select Geographic Coordinate System. This panel reports the Name, Description and Source of the current GCS.
Furthermore, how do I select attributes in MicroStation? Select By Attributes – Open the Select By Attributes dialog (effect is same as choosing Drawing > Home > Selection.
In this regard, how do you get an element selection box in MicroStation?
- Select the elements required to be changed.
- Choose the ‘Change Element Attributes’ tool from the Ribbon ( or popup menu )
- In the Tool Settings dialog, place a checkmark(s) against the attribute to change and select the required Attribute.
How do you match pattern attributes in MicroStation?
How do I get northing and easting in MicroStation?
- Answer: Go to Settings > Design File.
- Civil Formatting > Coordinate Settings and change Format to Northing, Easting. Click OK.
- Go to Tools > Civil AccuDraw > Civil AccuDraw Settings.
- Under the Favorites tab click Add and enter a name such as “NE”.
- Select the newly customized Civil AccuDraw command.
How do I change coordinates in MicroStation?
In the lower-right section of the MicroStation Window status bar, right-click the mouse and select Running Coordinates. Left-click the coordinate display on the status bar and select ACS Position. Change the Format, Accuracy and Direction Mode as required. Save the settings (File > Save Settings).
How do you move coordinates in MicroStation?
- Select the element(s) that needs to be moved*
- Activate the move command or the move reference command.
- Identify and accept the point to move from (use AccuSnap or Tentative. first)
- Enter: xy=#,#,150.
Where is select by attributes in MicroStation connect?
How do you select text in MicroStation?
If you are trying to select both text and text nodes, you will need to enter your string into each settings dialog. After you’ve entered the string you will search for, click back to the main Select By Attributes dialog, set it up for any other criteria you plan to search by, then click execute.
What is element selection tool?
Used to select and deselect elements for modification or manipulation. The set of selected elements is called the selection set . You can access this tool from the following: Ribbon: Drawing > Home > Selection.
How do I turn on reference display in MicroStation?
How do you display handles in MicroStation?
In MicroStation, when an element is selected, handles appear. These handles can be used to stretch an element (object). To turn off and on handle display, use the Disable Edit Handles setting on the Preferences dialog box, Operation category (Workspace > Preferences).
How do I change note attributes in MicroStation?
How do I change text attributes in MicroStation?
- Select or fence the text or tag element(s).
- Select the Change Text Attributes tool.
- Accept the change.
How do you match dimension attributes?
- Select the Match Dimension Settings tool.
- Identify the dimension element.
- Accept the new active dimension settings.
Is there a match properties in MicroStation?
To match element attributes anytime – even when you are already right in the middle of drawing an element. Press the “Alt”-key – move your cursor to the element you want to match the attributes from – left-mouse-click. The properties of the element become the active attributes.
How do you match hatch pattern in MicroStation connect?
- Create new element template.
- Add>Pattern/Hatch Settings.
- Change Area Pattern Is Annotation value to True(this should be the default value)
How do you cross hatch in MicroStation?
