Quick answer: How to change revision cloud line weight in revit?

1. In the project, click Manage tab Settings panel (Object Styles).
2. Click the Annotation Objects tab.
3. For Revision Clouds, change the values for Line Weight, Line Color, and Line Pattern.
4. Click OK. These changes apply to all revision clouds in the project.

Subsequently, how do you make revision clouds thicker in Revit? Click the Object Styles button near the bottom. Click the Annotation Tab at the top. Scroll down to Revision Clouds and there you can change the lineweight from 1 to whatever to get your thickness, you can also change the color there too. Seems to easy but worked great!

As many you asked, how do I change the scale of a revision cloud in Revit? Click View tab Sheet Composition panel (Sheet Issues/Revisions). On the Sheet Issues/Revisions dialog, enter a value for Arc Length. (The units for this value are determined by the Length project units.) Click OK.

Best answer for this question, how do you change revision sheets in Revit?

1. In the project, click View tab Sheet Composition panel (Sheet Issues/Revisions).
2. To add a new revision, click Add.
3. In the revision row, for Numbering, select Numeric, Alphanumeric, or None.
4. For Date, enter the date on which the revisions are made or will be sent for review.

Correspondingly, how do you change clouds in Revit?

1. In the project, open a view in which you want to indicate changes.
2. Click Annotate tab Detail panel (Revision Cloud).
3. On the Tools panel, click one of the draw tools.
4. In the drawing area, place the cursor near the part of the view that has changed and draw the cloud to encompass the changed area.

Type PEDIT on the command line and press enter, then select the revision cloud whose property you want to change. Select Width from the command line and specify the width for the revision cloud and press enter twice. You will notice that the width of revision cloud will change as per your specifications.

How do you change a revision sequence in Revit?

1. In the project, click View tab Sheet Composition panel (Sheet Issues/Revisions).
2. In the Sheet Issues/Revisions dialog, click the sequence number for the revision to move.
3. Under Row, click Move Up or Move Down.
4. Click OK.

How do I scale REV cloud?

On the Draw toolbar, click the Revision Cloud tool. Type revcloud and then press Enter. 2 Choose Arc Length. 3 Enter the minimum length of the individual arcs that make up the revision cloud, then press Enter.

How do I change the arc length of a revision cloud?

1. Click Home tab Draw panel Revision Cloud drop-down.
2. In the drawing area, right-click and choose the Arc length option.
3. Enter a new approximate chord length for the revision cloud arcs.

How do I add a revision Delta in Revit?

1. In the project, click View tab -> Sheet Composition panel -> Sheet Issues/Revisions.
2. The Sheet Issues/Revisions dialog displays.
3. To add a new revision, click Add.
4. In the revision row, for Numbering, select Numeric, Alphabetic, or None.

Where do you manage revisions in Revit?

Revit provides revision management through both the Revision Cloud tool, found on the Annotate tab, and through the use of the Revisions on Sheet dialog box found within the Sheet Properties. Ideate BIMLink provides access to the Revisions on Sheet properties, making revision management painless.

Where is the revision cloud in Revit?

To see or change revision cloud properties, select a revision cloud in a view, and make changes on the Properties palette.

How do you hide old revision clouds in Revit?

In a view, select one or more revision clouds, right-click, and click Hide in View Category. This tool hides all clouds in the view.

How do you use revision clouds?

From the Tools panel of the contextual tab, select the drawing tool to sketch the boundary of the revision cloud. Set the revision parameter to establish which revision the cloud belongs to. Place clouds where required. As you place revision clouds, use the spacebar to flip the orientation of the arcs of the cloud.

How do I change a Revcloud to a polyline?

“Select a revision cloud you want to fix. Right-click and go to Polyline > Decurve. The revision cloud will change to a flattened polyline.

How do I change the arc length in AutoCAD cloud?

1. Click Home tab Draw panel Revision Cloud drop-down. Find.
2. In the drawing area, right-click and choose Arc length.
3. Specify a new minimum arc length.
4. Specify a new maximum arc length.
5. Press Enter to continue with the command or Esc to end the command.

How do you add a revision triangle in AutoCAD?

How do I change my revision number in Revit 2020?

Use the Sheet Issues/Revisions dialog to specify the numbering scheme to use for each revision. Optionally, click the Numeric button under Numbering options to change the starting number for the numeric sequence (defaults to 1), and to add a prefix or suffix to be displayed with each value in the sequence.

What is Revcloud?

Revision clouds are closed polylines that form cloud-shaped objects consisting of arc segments. If you review or markup drawings, you can use the revision cloud feature to call attention to portions of each drawing.

What are the two options for creating splines in AutoCAD?

A 1-degree spline results in a line; there is no bend. A 2-degree spline results in a parabola; there can be only one bend. A 3-degree spline results in a cubic Bezier curve; there can be two bends.

How do I change my revision cloud tag number in Revit?

Click Annotate tab Tag panel (Tag By Category). In the drawing area, select the revision clouds to tag. As you select each cloud, Revit LT displays a revision tag next to it. Numbers in the tags reflect the revisions assigned to the clouds.

How do you create a revision cloud in PDF?

Choose Comment Menu > Drawing Tools > Draw Cloud.

How do I use Revcloud in AutoCAD 2018?

1. Click Home tab Draw panel Revision Cloud drop-down. Find.
2. In the drawing area, right-click and choose Object.
3. Select a circle, ellipse, polyline, or spline that you want to convert to a revision cloud.
4. Press Enter to keep the current direction of the arcs.
5. Press Enter.

How many selection methods are there in AutoCAD?

There are 18 different ways to select something in AutoCAD. Let’s look at these tools from the very basic that you might already know, to the super-secret ones. You can pick single object when AutoCAD asks you to select objects. You can define a crossing window selection by clicking at two points.

How do I change my revision number in AutoCAD?

The resource for the revision number displayed in the revision tag is the corresponding revision table. When you create a revision tag, it displays the revision number from the active row. To display another revision number, right-click the revision tag, and then select a revision number from the Tag list.

What is a revision symbol?

The revision symbol uses the revision table’s settings for the shape and revision number or letter. Click in the graphics area to place the symbol. You can place the symbol anywhere, and you can place multiple instances of the symbol while the Revision Symbol PropertyManager is active.
